Trenchers

T109 Hydraulic Trencher with standard teeth

  • Overall Width
    56.0 in
  • Standard Boom Length
    36 in
  • Overall Length
    92.0 in
  • Cutting Width
    6 in
Overall Width
56.0 in
Standard Boom Length
36 in
Overall Length
92.0 in
Cutting Width
6 in
Unit Weight
875.0 lb
Chain Type
Standard
Required Hydraulics
Standard Flow
Height
30.9 in
Overall Width
56.1 in
Drive Shaft Torque
1068.0 lb ft
Overall Length
92.4 in
Weight
1076.1 lb
Hyd Flow Range
42-83 L/min (11-22 gpm)
Overall Height
30.9 in
Hyd Pressure Range
145-235 bar (2,100-3,400 psi)
Required Hydraulic Flow
42-86 L/min (11-23 gpm)
Optimal Hydraulic Flow
42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure
145-235 bar (2100-3400 psi)
Drive Method
Geroter motor, direct
Drive Shaft Speed at Maximum Flow
203 rpm
Motor Displacement
24 in³
Motor Displacement
24.0 in3
Side Shift Travel
16.5 in
Drive Shaft Torque
1068 lb/ft
Maximum Auger Clearance
21 in
Spoil Auger Diameter
18 in
Optional Cutting Widths
203, 254, 305 mm (8, 10, 12 in)
Chain Pull at Maximum Pressure
2661 lb
Chain Speed at Maximum Flow
509 ft/min
Sideshift Control
Hydraulic or manual available
