Asphalt Pavers

AP1000 Wheel Paver

  • Paving Range with SE60 FM
    3.0 m - 7.8 m (10' - 25' 6")
  • Gross Power
    225 hp
  • Engine Model
    Cat C7.1
  • Maximum Travel Speed
    12 mile/h
Dimensions
Paving Range with SE60 FM
3.0 m - 7.8 m (10' - 25' 6")
Paving Range with SE60 V
3.0 m - 7.65 m (9' 10" - 25')
Paving Range with SE60 V XW
3.0 m - 7.5 m (10' - 24' 6")
Paving Range with SE60 VT XW
3.0 m - 6 m (10' - 19' 6")
Operating Length
22.3 ft
Operating Width
10.8 ft
Overall Height
12.3 ft
Transport Length
20.9 ft
Transport Width
11.9 ft
Transport Height
9.8 ft
Engine
Gross Power
225 hp
Engine Model
Cat C7.1
Operating Specifications
Maximum Travel Speed
12 mile/h
Maximum Paving Speed
250 ft/min
Maximum Paving Speed
82 ft/min
Inside Turn Radius
4.5 ft
Maximum Throughput Capacity
1766 ton(US)/h
Weights
Operating weight with SE60 FM
42620 lb
Operating weight with SE60 V
42360 lb
Operating weight with SE60 V XW
43848 lb
Shipping Weight
34228 lb
Service Refill Capacities
Fuel Tank Capacity
92 gal (US)
DEF Tank
5 gal (US)
Cooling System
12 gal (US)
Hydraulic Oil Tank
58 gal (US)
Washdown Spray Tank
7.9 gal (US)
  • Electrical system
    • 70 kW generator
    • Cat Electronic Technician
    • Machine security system
    • Remote jump start receptacle
    • Automotive type fuse system
    • 12-volt power receptacle
    • 100 amp alternator
    • 1000 CCA batteries
  • Material Delivery
    • Contact-type material feed sensors
    • Adjustable push-roller
  • Service and Maintenance
    • Extended-life coolant
    • Remote access drains
    • Scheduled Oil sampling ports
    • Sight gauges
  • Safety
    • Back-up alarm
    • Horn
    • Working lights
    • Mirror package
    • Vandal covers
  • Operating Environment
    • Dual operating stations
    • Steering guide
    • Ventilation System
  • Technology
    • Product Link™ Elite 641_cellular
  • Powertrain
    • Automatic engine speed control
    • Cat C7.1 Engine
    • Variable speed cooling fan
    • Eco-mode
    • Extended life hydraulic oil
  • Technology
    • Cat Grade Control
    • Hopper level and material height sensor
    • Pave start assistant
    • Product Link™ Elite 631_satellite
    • Thermal mapping
  • Powertrain
    • All wheel drive
    • Ballast_front weights
    • Front wheel assist
    • Radial drive tires
    • Sand rib drive tires
  • Electrical System
    • Auxiliary power panel_6.6 kW
  • Operating Environment
    • Air-ride seat
    • Windshield
    • Hard top canopy
    • Deceleration pedal
    • Heated seats
    • Side shields
    • Towpoint indicator (2nd)
    • Umbrella
    • Ventilation system
    • Screen visor
  • Material Delivery
    • Auger extension
    • Leveling devices
    • Mainframe extensions_manual
    • Mainframe extensions_power
    • Sonic feed sensors
    • Power folding front apron
    • Truck hitch
    • Washdown pump and reel
    • Washdown tank
    • Wide width paving packages
  • Service and Maintenance
    • Service repair kits
    • Uptime kits
  • Grade References
    • Sonic Averaging Beam
    • Rigid Ski, 9.15 m (30') and 12.2 m (40')
  • Screed Choices
    • SE60 V XW Screed
    • SE5 VT XW Screed
    • SE60 V Screed
    • SE60 FM Screed
    • SE60 FM Screed
