Asphalt Pavers

AP1055 Mobil-Trac Paver

  • Gross Power
    225 HP
  • Paving Range with SE60 V
    3.0 m - 7.65 m (9' 10" - 25')
  • Engine Model
    Cat C7.1
  • Engine Power
    225 hp
Engine
Gross Power
225 HP
Engine Model
Cat C7.1
Engine Power
225 hp
Engine Model
Cat C7.1
Dimensions
Paving Range with SE60 V
3.0 m - 7.65 m (9' 10" - 25')
Paving Range with SE60 FM
3.0 m - 7.8 m (10' - 25' 6")
Paving Range with SE60 V XW
3.0 m - 10 m (10' - 33')
Paving Range with SE60 VT XW
3.0 m - 10 m (10' - 33')
Operating Length
22.3 ft
Operating Width
10.8 ft
Overall Height
12.25 ft
Transport Length
21.9 ft
Transport Width
9.8 ft
Transport Height
9.7 ft
Operating Specifications
Maximum Travel Speed
9 mile/h
Maximum Paving Speed
210 ft/min
Maximum Paving Speed
82 ft/min
Inside Turn Radius
1.5 ft
Maximum Throughput Capacity
1602 ton(US)/h
Weights
Operating weight with SE60 V
45087 lb
Operating weight with SE60 FM
45352 lb
Operating weight with SE60 V XW
46573 lb
Shipping Weight
36800 lb
Service Refill Capacities
Fuel Tank Capacity
92 gal (US)
DEF Tank
5 gal (US)
Cooling System
12 gal (US)
Hydraulic Oil Tank
58 gal (US)
Washdown Tank
7.9 gal (US)
  • Operating Environment
    • Dual operating stations
    • Steering guide
    • Ventilation System
  • Technology
    • Product Link™ Elite 641_cellular
  • Powertrain
    • Automatic engine speed control
    • Cat C7.1 Engine
    • Variable speed cooling fan
    • Eco-mode
    • Extended life hydraulic oil
  • Electrical system
    • 70 kW generator
    • Cat Electronic Technician
    • Machine security system
    • Remote jump start receptacle
    • Automotive type fuse system
    • 12-volt power receptacle
    • 100 amp alternator
    • 1400 CCA batteries
  • Material Delivery
    • Contact-type material feed sensors
    • Adjustable push-roller
  • Service and Maintenance
    • Extended-life coolant
    • Remote access drains
    • Scheduled Oil sampling ports
    • Sight gauges
  • Safety
    • Back-up alarm
    • Horn
    • Working lights
    • Mirror package
    • Vandal covers
  • Technology
    • Cat Grade Control
    • Hopper level and material height sensor
    • Pave start assistant
    • Product Link™ Elite 631_satellite
    • Thermal mapping
  • Operating Environment
    • Air-ride seat
    • Hard top canopy
    • Deceleration pedal
    • Friction steering
    • Heated seats
    • Side shields
    • Towpoint indicator (2nd)
    • Umbrella
    • Screen visor
    • Windshield
  • Powertrain
    • Ballast_front weights
    • Mobil-trac belt - smooth
    • Mobil-trac belt - tread bar
  • Electrical System
    • Auxiliary power panel_6.6 kW
  • Material Delivery
    • Auger extension
    • Leveling devices
    • Mainframe extensions_manual
    • Mainframe extensions_power
    • Sonic feed sensors
    • Power folding front apron
    • Truck hitch
    • Washdown pump and reel
    • Washdown tank
    • Wide width paving packages
  • Service and Maintenance
    • Service repair kits
    • Uptime kits
  • Screed Choices
    • SE60 V Screed
    • SE60 FM Screed
    • SE5 VT XW Screed
    • SE60 V XW Screed
  • Grade References
    • Sonic Averaging Beam
    • Rigid Ski, 9.15 m (30') and 12.2 m (40')
