CB1.8 Utility Compactor

  • Operating Weight
    3825 lb
  • Standard Compaction Width
    39 in
  • Curb Clearance
    16 in
  • Ground Clearance
    10 in
Weights
Operating Weight
3825 lb
Operating Specifications
Standard Compaction Width
39 in
Curb Clearance
16 in
Ground Clearance
10 in
Static Linear Load
63 lb/in
Travel Speed
5.3 mile/h
Turning Radius
75 in
Engine
Gross Power
24.7 hp
Engine Model
Cat C1.1
Dimensions
Overall Length
80 in
Overall Width
44 in
Drum Diameter
22.5 in
Drum Width
39 in
Maximum Machine Height
94.5 in
Vibratory System
Frequency
3420 V/m
Centrifugal Force per Drum
3057 lb
Nominal Amplitude
0.018 in
Service Refill Capacities
Fuel Tank Capacity
7.9 gal (US)
Water Spray Tank Capacity
38 gal (US)
  • Operator Environment
    • ROPS Folding
    • Operator Console w/ Emergency Stop, Simple Rocker Switches, and Machine Warning Indicator Lights
    • Dual 12-volt Power Outlet
    • Horn, Backup Alarm
  • Compaction System
    • Folding Scrapers
    • Vibe Selection - Front, Rear, or Both
    • Pressurized, Triple-Filtration Spray System
  • Powertrain
    • Air Cleaner, Dual Element
    • Engine Belt Guard
  • Technology
    • ProductLinkTM
  • Electrical
    • Working Lights
  • Other
    • Vandal Protection - Lockable Hood and Controls Cover
    • Machine Life and Tiedowns
  • Operator Environment
    • Adjustable Suspension Seat w/ Operator Presence Switch
    • ROPS Fixed
  • Electrical
    • Battery Disconnect
    • Roading Lights
    • Rotating Amber Beacon
    • Light Guards
  • Other
    • Single Point Lift
