New 317 GC Hydraulic Excavator for Sale

317 GC Hydraulic Excavator

Net Power

119 hp
Engine Model

Cat C3.6
Engine Power

121 hp
Engine Power

122 hp (metric)

Engine

Net Power: 119 hp
Engine Model: Cat C3.6
Engine Power: 121 hp
Engine Power: 122 hp (metric)
Net Power: 121 hp (metric)
Bore: 4 in
Stroke: 5 in
Displacement: 220 in³
Biodiesel Capability: Up to B20¹
Emissions: Meets U.S. EPA Tier 4 Final and EU Stage V emission standards
Note: Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,400 rpm. Advertised power is tested per the specified standard in effect at the time
Note: ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO

Hydraulic System

Main System: 296 L/min (78 gal/min)
Maximum Pressure: 5075 psi
Maximum Pressure: 5075 psi
Maximum Pressure: 3741 psi

Swing Mechanism

Swing Speed: 8.7 r/min
Maximum Swing Torque: 44990 lbf·ft

Weights

Operating Weight: 38000 lb

Service Refill Capacities

Fuel Tank Capacity: 71.6 gal (US)
Cooling System: 5.8 gal (US)
Engine Oil: 2.9 gal (US)
Final Drive: 1.6 gal (US)
Hydraulic System: 24.8 gal (US)
Hydraulic Tank: 23 gal (US)
DEF Tank: 5.9 gal (US)

Dimensions

Boom: Reach 5.1 m (16'9")
Stick: Reach R2.9 m (9'6")
Bucket: GD 0.76 m³ (0.99 yd³)
Shipping Height: 9.6 ft
Handrail Height: 9.7 ft
Shipping Length: 28.1 ft
Tail Swing Radius: 8.2 ft
Counterweight Clearance: 3.3 ft
Ground Clearance: 1.4 ft
Track Length: 13 ft
Length to Center of Rollers: 10.4 ft
Track Gauge: 6.5 ft
Transport Width: 8.5 ft

Working Ranges and Forces

Maximum Digging Depth: 21 ft
Boom: Reach 5.1 m (16'9")
Stick: Reach R2.9 m (9'6")
Bucket: GD 0.76 m³ (0.99 yd³)
Maximum Reach at Ground Level: 29.6 ft
Maximum Cutting Height: 29.2 ft
Maximum Loading Height: 20.6 ft
Minimum Loading Height: 6.5 ft
Maximum Depth Cut for 2440 mm: 20.3 ft
Maximum Vertical Wall Digging Depth: 16.3 ft
Minimum Working Equipment Radius: 9.7 ft
Bucket Digging Force: 27650 lbf
Stick Digging Force: 16860 lbf

Air Conditioning System

Air Conditioning: The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.9 hg of refrigerant which has a CO2 equivalent of 1.418 metric tonnes.

NOTE
- Standard and optional equipment may vary. Consult your Cat dealer for details.
BOOM AND STICKS
- 5.1 m (16'9") Reach Boom
CAB
- Rollover protective structure (ROPS)
- Air suspension seat, 203 mm (8") LCD touchscreen monitor
CAT TECHNOLOGIES
- VisionLink^®
- Remote Flash
- Remote Troubleshoot
ELECTRICAL SYSTEM
- Maintenance free battery
- LED chassis light and left-side boom light
- Programmable time-delay LED working lights
- Centralized electrical disconnect switch
ENGINE
- Cat C3.6 single turbo diesel engine
- Two selectable modes: Power, Smart
- Automatic engine speed control
- Automatic engine idle shutdown
- Electric fuel priming pump
- Electric cooling fans
- Single fuel filtration system with water separator and indicator
- Sealed double element air filter with integrated precleaner
- Biodiesel capability up to B20
HYDRAULIC SYSTEM
- Boom and stick regeneration circuits
- Auto hydraulic oil warm up
- Auto two-speed travel
- Electric main control valve
- Boom and stick drift reduction valve
- Element-type main hydraulic filter
- Single-type electronic main pump
SAFETY AND SECURITY
- Rear and right-side-view cameras
- Ground-level engine shutoff switch
- Service platform with anti-skid plate and countersunk bolts
- Signaling/warning horn
- Hydraulic lock out lever
SERVICE AND MAINTENANCE
- Side entry to service platform
- Grouped engine oil and fuel filters
- Ground-level engine oil dipstick
- Sampling ports for Scheduled Oil Sampling (S·O·S)
UNDERCARRIAGE AND STRUCTURES
- Grease lubricated track link
- Tie down points on base frame

NOTE
- Standard and optional equipment may vary. Consult your Cat dealer for details.
BOOM AND STICKS
- 2.6 m (8'6") Reach stick
- 2.9 m (9'6") Reach stick
- 2.9 m (9'6") Thumb ready stick
- 3.1 m (10'2") Reach stick
CAB
- Operator Protective Guards (OPG)
CAT TECHNOLOGIES
- VisionLink Productivity
ELECTRICAL SYSTEM
- LED chassis light, right-side boom light and cab lights
ENGINE
- -18°C (-0°F) cold start capability
- -25°C (-13°F) cold start capability
SAFETY AND SECURITY
- Swing alarm
- Inspection lighting
SERVICE AND MAINTENANCE
- Integrated vehicle health management system
UNDERCARRIAGE AND STRUCTURES
- 600 mm (24") triple grouser track shoes
- 600 mm (24") rubber track shoes
- 700 mm (28 in) triple grouser track shoes
- 3.05 mt (6,720 lb) counterweight
- 3.57 mt (7,870 lb) counterweight
