Excavators

365C L Large Hydraulic Excavator

  • Engine Model
    C15 ACERT
  • Net Flywheel Power
    411 hp
  • Net Power
    404 hp
  • Bore
    5.4 in
Engine
Engine Model
C15 ACERT
Net Flywheel Power
411 hp
Net Power
404 hp
Bore
5.4 in
Stroke
6.75 in
Displacement
928 in³
Weights
Operating Weight
157850 lb
Operating Specifications
Maximum Reach
46.26 ft
Maximum Digging Depth
31.17 ft
Bucket Digging Force
43400 lb
Stick Digging Force
59600 lb
Maximum Bucket Capacity
5 yd³
Nominal Bucket Weight
4210 lb
Bucket Digging Force
59600 lb
Track
Standard with Long Undercarriage
36 in
Optional for Long Undercarriage
30 in
Optional for Long Undercarriage
26 in
Number of Shoes
47
Number of Track Rollers
8
Number of Carrier Rollers
3
Swing Mechanism
Swing Speed
6.5 r/min
Swing Torque
150850 lb/ft
Drive
Maximum Travel Speed
2.6 mile/h
Maximum Drawbar Pull
103767 lb
Hydraulic System
Main System
212 gal/min
Swing System
94 gal/min
Maximum Pressure
4640 psi
Maximum Pressure
5080 psi
Maximum Pressure
5080 psi
Maximum Pressure
4060 psi
Pilot System
24 gal/min
Pilot System
600 psi
Boom Cylinder
7.5 in
Boom Cylinder
70.6 in
Stick Cylinder
7.9 in
Stick Cylinder
83.4 in
VB Family Bucket Cylinder
7.1 in
VB Family Bucket Cylinder
56.8 in
WB Family Bucket Cylinder
7.9 in
WB Family Bucket Cylinder
57.4 in
Service Refill Capacities
Fuel Tank Capacity
211 gal (US)
Cooling System
25 gal (US)
Engine Oil
14.3 gal (US)
Swing Drive
3.2 gal (US)
Final Drive
4 gal (US)
Hydraulic System
177 gal (US)
Hydraulic Tank
82 gal (US)
Sound Performance
Performance
ANSI/SAE J1166 OCT98
Standards
Brakes
SAE J1026 APR90
Cab
SAE J1356 FEB88 ISO10262
