Auxiliary Engines

Cat C32 Auxiliary/Generator Set Engine

  • Power Range
    791-1333
  • Rated Engine Speed
    1500 / 1800
  • Emissions
    IMO II, IMO III, U.S. Tier 4, EU Stage V, China II
  • Minimum Rating
    1047.0 bhp
Power Rating
Power Range
791-1333
Minimum Rating
1047.0 bhp
Minimum Rating
1047 BHP
Maximum Rating
1333 BHP
Engine Specifications
Rated Engine Speed
1500 / 1800
Emissions
IMO II, IMO III, U.S. Tier 4, EU Stage V, China II
Aspiration
TTA
Aspiration
Turbocharged Aftercooled
Rotation
Counterclockwise
Stroke
6.4 in
Displacement
1959.0 in3
Configuration
Vee 12, 4-Stroke-Cycle Diesel
Bore
5.7 in
Bore
5.7 in
Configuration
V 12, 4-Stroke-Cycle Diesel
Displacement
1959 in³
Rotation from Flywheel End
Counterclockwise
Stroke
6.4 in
Dimensions & Weights
Minimum Dry Weight
6950.0 lb
Maximum Dry Weight
7160.0 lb
Minimum Length
83.5 in
Maximum Width
60.2 in
Minimum Height
60.9 in
Maximum Height
62.5 in
Minimum Width
60.2 in
Maximum Length
89.9 in
Maximum Dry Weight
7160 lb
Maximum Height
62.5 in
Maximum Length
89.9 in
Maximum Width
60.2 in
Minimum Dry Weight
6950 lb
Minimum Height
60.9 in
Minimum Length
83.5 in
Minimum Width
60.2 in
Length
89.9 in
Engine Dry Weight
6956
Width
60.2 in
Height
62.4 in
Dry Weight
6956 lb
  • AIR INLET SYSTEM
    • Separate circuit after-cooled (SCAC)
    • Air cleaner
    • Turbocharger, jacket water cooled
    • Turbocharger inlet, 152 mm (6 in) OD straight connection
  • CONTROL SYSTEM
    • Programmable Low Idle (550 - 750 rpm)
    • Programmable High Idle Limit for WOSR Ratings
    • Electronic diagnostics and fault logging
    • Engine and transmission monitoring (speed, temperature, pressure)
    • Electronic fuel/air ratio control
    • Engine Protection Mode for extended ambient conditions
    • 70-pin customer connector
    • Throttle Input signal options
    • 0 - 5 Volts
    • 4 - 20 mA
    • PWM (Pulse Width Modulated)
  • COOLING SYSTEM
    • Separate Circuit After-Cooling (SCAC) for both HEX and Keel cooled engines
    • Jacket Water (JW) and SCAC Heat Exchangers Shell & Tube for HEX cooled engines
    • SCAC pump, gear driven
    • Jacket water pump, gear driven
    • Sea water pump, bronze impeller, gear driven, when selected for Hex cooled engines
    • Sea water Pump & JW Heat Exchanger Connection: 76.2 mm (3in) ID Standard 4 Bolt ANSI Flange Connection
    • Keel Connections: 76.2 mm (3in) ID Standard 4 Bolt
    • SCAC and JW shunt tanks for maintaining proper pump inlet pressures
  • EXHAUST SYSTEM
    • Water-cooled exhaust manifold & turbocharger
    • 4 Bolt 130 mm (5.12 in) diameter flanged outlet
  • FLYWHEELS & FLYWHEEL HOUSINGS
    • SAE standard rotation (CCW facing exciter end)
    • Flywheel Housing: SAE No. 0, Flywheel: 18 inch, 136 teeth
  • FUEL SYSTEM
    • Duplex Fuel Filters, Spin-on, RH & LH service
    • Fuel connections size: r driven
    • Plate-type fuel cooler installed behind Aftercooler Shunt Tank
    • Fuel transfer pump, gear driven
    • Manual fuel priming pump
    • Hybrid fuel line design
  • LUBE SYSTEM
    • Simplex Oil Filters, RH or LH service
    • Deep sump oil pan
    • RH or LH service oil filler locations
    • RH or LH service dipstick
    • Oil pump, gear driven
  • MOUNTING SYSTEM
    • Front support - 33 inches wide
  • POWER TAKE-OFFS
    • Front Poly-V groove pulley (Quantity 1) for auxiliary drives
  • GENERAL
    • Common electrical bonding point
    • Engine does not ship with zinc components
  • EXHAUST SYSTEM
    • Dry Elbows
    • Flexible Fitting
    • Flange
    • Muffler
    • Muffler Spark Arresting
  • AIR INLET SYSTEM
    • Air Inlet Adapter
  • CHARGING SYSTEM
    • Battery Chargers
    • Charging Alternators
    • Ammeter
  • CONTROL SYSTEM
    • Load Sharing Attachment
    • Instrument Panels
    • Caterpillar Alarm Protection
    • Fuel and Oil Shielding
  • FUEL SYSTEM
    • Water Separator
  • GENERAL
    • FUMES DISPOSAL SYSTEM
  • INSTRUMENTATION
    • Instrument Panels
    • OEM Wiring Harness
    • Engine to Engine Harness
    • Gauges
    • Transmission Sensors
    • Exhaust Temperature Sensors
  • LUBE SYSTEM
    • Duplex Oil Filters
    • Sump Pump
  • POWER TAKE-OFFS
    • Rear Hydraulic Pump Drive
  • STARTING SYSTEM
    • Electric Starting Motors - Single 24 Volt
    • Air Starting Motor
    • Dual Starting Motors (Electric and Air)
    • Air Start Accessories
    • Starting Aids - JW Heaters
    • Battery Sets - 24 Volt - Dry
  • MOUNTING SYSTEM
    • Front Support
    • Rear Support
    • Isolators Mounts
    • Adapter Kits
  • PACKING
    • Engine Protective Cover
    • Storage Preservation
    • Export Packing
