New Cat?� 3508 Fire Pump for Sale

Cat?� 3508 Fire Pump

Minimum Power

950.0 bhp
Maximum Power

1065 hp
Maximum Power

1065.0 bhp
Rated Speed

1460-1750 rpm

Power Rating

Minimum Power: 950.0 bhp
Maximum Power: 1065 hp
Maximum Power: 1065.0 bhp
Rated Speed: 1460-1750 rpm
Minimum Power: 950 hp
Rated Speed: 1460-1750 rpm

Emission Standards

Emissions: Non-Certified. Available for global non-regulated areas. Not FM Approved, Not UL Listed
Emissions: Non-Certified. Available for global non-regulated areas. Not FM Approved, Not UL Listed

General

Engine Configuration: V-8, 4-Stroke-Cycle Diesel
Bore: 6.7 in
Bore: 170 mm (6.7 in)
Stroke: 7.5 in
Displacement: 2105 in³
Stroke: 190 mm (7.5 in)
Compression Ratio: 13.0:1
Aspiration: Turbocharged Aftercooled (TA)
Displacement: 34.5 L (2105 in³)
Aspiration: Turbocharged Aftercooled (TA)
Rotation from Flywheel End: Counterclockwise
Compression Ratio: 13.0:1
Aftertreatment: -
Rotation: Counterclockwise

Engine Dimensions - Approximate

Length: 92.5 in
Height: 74.9 in
Weight: 11805 lb
Height: 1902.4 mm (74.9 in)
Length: 2350.4 mm (92.5 in)
Weight: 5355 kg (11805 lb)

Air Inlet System
- Air cleaner. Regular duty, dry, panel type with service indicators, turbocharger, jacket water aftercooled.
- Turbocharger, rear mounted
- Jacket water aftercooled
Control System
- Charging alternator 24 volt, 35 amp
- Governor, RH, 3161 with self contained synthetic oil sump
- Air-fuel ratio control
- Mechanical speed control, without torque control
- Governor control
- Positive locking
Cooling System
- Thermostats and housing
- Jacket water pump, centrifugal
Exhaust System
- Exhaust manifold, dry
Flywheels and Flywheel Housing
- SAE No. 0 flywheel
- 151 flywheel teeth
- SAE No. 0 flywheel housing
- SAE standard rotation
Fuel System
- Fuel filter, with service indicators, cartridge type with RH service
- Fuel transfer pump
Instrumentation
- Instrument Panel, RH
- Engine oil pressure gauge
- Fuel pressure gauge
- Oil filter differential gauge
- Jacket water temperature gauge
- Service meter, electric
- Tachometer
Lube System
- Crankcase breather, top mounted
- Oil cooler
- Oil filler
- Oil dipstick
- Oil pump
- Oil filter, cartridge type with RH service
- Shallow oil pan
- Fumes disposal (not installed)
Mounting System
- Rails, mounting, engine length, 254 mm (10 in), industrial-type, C-channel.
- Included on selected top level engines
Power Take Off
- Accessory drive, upper RH
- Front housing, single sided
Protection System
- Junction box
- Manual shutoff, RH
- Safety shutoff protection, energized to shutdown
- Low oil pressure, low idle 69 kPa (10 psi); high idle 207 kPa (30 psi)
- Water temperature
- Overspeed
- 3161 governor solenoid energized to shutdown
Starting System
- Starting switch
General
- Vibration damper
- Lifting eyes
- Paint: Caterpillar yellow, with optional colors available at request
