Electric Power
XQ1475G
-
Rating1475 ekW Continuous
-
Continuous1475kW / 1844KVA
-
Rating1475 ekW Continuous
-
Voltage230 - 480 V
Generator
- Rating
- 1475 ekW Continuous
- Continuous
- 1475kW / 1844KVA
- No
- 4
- Excitation
- Static regulated brushless PM excited
- Constructions
- Double bearing, close coupled
- Insulation
- Class H
- Frame Size
- 826
- Pitch
- 0.6667
- Alignment
- Pilot shaft
- Overspeed capability
- 125% of rated
- Voltage regulator
- 3 phase sensing with Volts-per-Hertz
- Voltage regulation
- Less than ± 0.5% voltage gain Adjustable to compensate for engine speed droop and line loss
- Wave form deviation
- Less than 3% deviation
- Telephone Influence Factor
- Less than 50
- Harmonic Distortion
- Less than 5%
Generator Set
- Rating
- 1475 ekW Continuous
- Voltage
- 230 - 480 V
- Frequency
- 50/60 Hz
Engine
- Number of Cylinders
- V16
- Bore
- 6.7 in
- Stroke
- 7.5 in
- Displacement
- 4210 cu in
- Compression ratio
- 11.3:1
- Engine
- Cat G3516C Low Emissions Gas Engine
- Engine
- Cat G3516C Low Emissions Gas Engine
- Engine Speed
- 1500/1800
- Fuel
- Natural Gas
- Aspiration
- Turbocharged Separate Circuit Aftercooled
- Aftercooler Inlet
- 92
- Fuel
- Natural Gas
- Jacket Water Outlet
- 98
- Exhaust Manifold
- Dry
- Fuel system
- Cat Low Pressure w/ Air Fuel Ratio Control
- Governor type
- ADEM™ A3 Control System
- Combustion
- Low Emission
- Fuel Pressure Range
- 3-7
- Methane Number
- 55-100
Dimension
- Weight
- 79372 lb
Dimensions
- Width
- 96 in
- Width
- 96 in
- Height
- 114 in
- Height
- 114 in
- Length
- 480 in
- Length
- 480 in
- Weight
- 70372 lb
- Weight
- 70372 lb
-
Engine
- Cat G3516C Island mode gas engine (Operates on 31.5 to 47.2 MJ/Nm3 (800 to 1200 btu/ft3) dry pipeline natural gas)
-
Generator
- Double bearing SR-4B brushless, form wound, permanent magnet excited, thouree-phase with Cat digital voltage regulator (Cat DVR), space heater, 6-lead design, Class H insulation operating at Class F temperature for extended life, winding temperature detectors and anti-condensation space heaters (120/240V 1.2 kW).
-
Containerized Module
- 40' ISO high cube container, 9-high stack CSC certified
-
Cooling
- Standard cooling provides 40C (104F) ambient capability with 500mg/Nm3 NOx at 100% Continuous
-
Generator Controls and Protection
- Controls provide auto paralleling AGC-4 controller, CAN-bus, ethernet comm, PWM and analog outputs, legacy analog load sharing; includes PL1000E gas engine Advisor panel for operational/diagnostic information; cabinet houses shore power transformer, distribution, protection, and internal/external power selector switch.
-
Utility Multi-Functional Relay
- Intertie protection provided via utility grade Basler BE1-11i
-
Trailer
- 3-axle chassis
- Ladders, handrails, internal storage provisions
