Electric Power
XQ425
-
Rating375 ekW (470 kVA) Standby
-
Rating340 ekW (425 kVA)
-
Rating Prime340 ekW (425 kVA)
-
Frequency50/60 Hz
Generator
- Rating
- 375 ekW (470 kVA) Standby
- Rating
- 340 ekW (425 kVA)
- Rating Standby
- 375 ekW (469 kVA)
- Frame Size
- SR4B – 450
- Pitch
- 0.750
- Prime Rating
- 340 kW
- Number of bearings
- Single bearing, close coupled
- Insulation
- Class H
- Temperature rise
- 105 C
- Enclosure
- Drip proof IP23
- IPP Rated 60Hz
- 74 dB(A)
- Overspeed capability
- 125% of rated
- Voltage regulator
- 3 phase sensing with Volts-per-Hertz
- Voltage regulation
- Less than ± 1⁄2% voltage gain Adjustable to compensate for engine speed droop and line loss
- Wave form deviation
- 3%
- Telephone Influence Factor
- Less than 50
- Harmonic Distortion
- Less than 5%
Generator Set
- Rating Prime
- 340 ekW (425 kVA)
- Frequency
- 50/60 Hz
- Voltage
- 120 - 600 V
- Rating Standby
- 375 ekW (469 kVA)
Engine
- Engine
- C13
- Fuel
- Diesel
- Bore
- 5.10 in
- Stroke
- 6.20 in
- Displacement
- 763 in3
- Compression ratio
- 17.0:1
- Engine RPM
- 1500-1800
- Aspiration
- TA
- Aftercooler type
- ATAAC
- Fuel
- Requires ULSD
- Turbocharger
- Single
- Fuel system
- MEUIC
- Governor type
- ADEM™ A4
- Cat
- C13 ATAAC, I-6 4-stroke water cooled diesel
Dimensions
- Height
- 60 in
- Length
- 208.7 in
- Width
- 104 in
- Weight
- 14700 lb
- Weight with Lube Oil and Coolant
- 14700 lb
- Width
- 102 in
- Height
- 126.1 in
- Length
- 283.7 in
- Weight
- 14700 lb
- Weight
- 17930 lb
Fuel Consumption Prime
- 100
- 23.1 gal/hr
- 75
- 17.7 gal/hr
- 50
- 12.7 gal/hr
Fuel Consumption
- 100
- 23.1 gal/hr
- 75
- 17.7 gal/hr
- 50
- 12.7 gal/hr
- 100
- 25.1 gal/hr
- 75
- 19.2 gal/hr
- 50
- 13.6 gal/hr
Fuel Consumption Standby
- 100
- 25.1 gal/hr
- 75
- 19.2 gal/hr
- 50
- 13.6 gal/hr
Noise rating (with enclosure)
- Sound Power
- 74 dB(A)
-
CAT C13 Diesel Engine
- Heavy-duty.
Turbocharged.
After treatment
- Heavy-duty.
-
Generator
- SR4B - 450 Frame
-
Control Panel
- Digital EMCP4.2 set mounted controller
-
Cat Connect remote monitoring
- Provides package monitoring and management
-
Cooling System
- Package mounted radiator with vertical air discharge.
Filled from factory
- Package mounted radiator with vertical air discharge.
-
Charging / Starting System
- 12V heavy duty starting motor and charging alternator c/w battery isolator
-
Fuel System
- 24 hour dual wall fuel tank with 3 way directional valve for external supply
-
Air Filter
- Cyclonic/paper with dust cup and service indicator
-
Distribution
- Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off
-
Structure
- Heavy Duty steel base frame with integral fuel tank.
Lifting frame and 4 point lift.
base frame is wider than enclosure to protect generator set during transportation
- Heavy Duty steel base frame with integral fuel tank.
-
Enclosure
- Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance
-
Exhaust
- Integrated spark arresting silencer
-
Lube Oil
- On engine primary and secondary oil filters. Filled from factory
-
General
- Factory tested and inspected
