Industrial
Cat?� C1.5 Diesel Engine
-
Minimum Power28.0 bhp
-
Maximum Power40.2 HP
-
Maximum Power40.2 hp
-
Maximum Power40.2 bhp
Power Rating
- Minimum Power
- 28.0 bhp
- Maximum Power
- 40.2 HP
- Maximum Power
- 40.2 hp
- Maximum Power
- 40.2 bhp
- Maximum Torque
- 83 lb-ft @ 1800 rpm
- Maximum Torque
- 83 lb-ft @ 1800 rpm
- Rated Speed
- 2200-3000 rpm
- Rated Speed
- 2200-3000 rpm
- Minimum Power
- 27.8 HP
- Minimum Power
- 27.8 hp
- Rated Speed
- 2200-3000 rpm
Emission Standards
- Emissions
- U.S. EPA Tier 4 Interim Equivalent
- Emissions
- U.S. EPA Tier 4 Interim Equivalent
- Emissions
- U.S. EPA Tier 4 Interim Equivalent
General
- Engine Configuration
- Inline 3, 4-Stroke-Cycle Diesel
- Engine Configuration
- Inline 3, 4-Stroke-Cycle Diesel
- Engine Configuration
- Inline 3, 4-Stroke-Cycle Diesel
- Bore
- 84 mm (3.3 in)
- Bore
- 84 mm (3.3 in)
- Bore
- 3.3 in
- Bore
- 3.3 in
- Stroke
- 3.5 in
- Stroke
- 3.5 in
- Stroke
- 90 mm (3.5 in)
- Stroke
- 90 mm (3.5 in)
- Displacement
- 91 in³
- Displacement
- 91 in³
- Displacement
- 1.496 L (91 in³)
- Aspiration
- Naturally Aspirated (NA) or Turbocharged (T)
- Displacement
- 1.496 L (91 in³)
- Compression Ratio
- 22.5:1
- Compression Ratio
- 22.5:1
- Compression Ratio
- 22.5:1
- Aspiration
- Naturally Aspirated (NA) or Turbocharged (T)
- Aspiration
- Naturally Aspirated (NA) or Turbocharged (T)
- Combustion System
- Indirect Injection
- Combustion System
- Indirect Injection
- Combustion System
- Indirect Injection
- Rotation
- Counterclockwise
- Rotation from Flywheel End
- Counterclockwise
- Rotation from Flywheel End
- Counterclockwise
- Aftertreatment
- -
- Aftertreatment
- -
- Lube System
- 6 L (6.3 qt)
- Lube System
- 6 L (6.3 qt)
Engine Dimensions - Approximate
- Length
- 22.5 in
- Length
- 22.5 in
- Width
- 20.3 in
- Width
- 20.3 in
- Height
- 25.3 in
- Height
- 25.3 in
- Weight
- 345 lb
- Weight
- 345 lb
- Height
- 643 mm (25.3 in)
- Length
- 572 mm (22.5 in)
- Weight
- 149-156.5 kg (328.5-345 lb)
- Width
- 453-512 mm (17.8-20.3 in)
Engine Dimensions (Approximate. Final dimensions dependent on selected options)
- Length
- 572 mm (22.5 in)
- Width
- 453-512 mm (17.8-20.2 in)
- Height
- 643 mm (25.3 in)
- Weight
- 149-156.5 kg (328-345 lb)
-
Air Inlet System
- Inlet manifold with choice of inlets.
-
Control System
- Alternator 12 volt 65 amp
- Starter motor 12 volt
- Glow plug starting aid
-
Cooling System
- Belt-driven coolant pump
- Coolant temperature switch
- Choice of cooling fans
-
Flywheel & Flywheel Housing
- Naturally Aspirated: SAE No. 7 1/2 flywheel
- Turbocharged: SAE No. 6 1/2 or SAE No. 7 1/2 flywheel
- Naturally Aspirated: Choice of SAE No. 4 or standard backplate flywheel housing
- Turbocharged: Choice of SAE No. 4 or SAE No. 5 or standard backplate flywheel housing
-
Fuel System
- Fuel injection pump
- Spin-on fuel filter
- Electronic Shut-off Solenoid (ESOS)
-
Lube System
- Alternative oil fillers
- Spin-on lube oil filter
- Lube oil pressure switch
- Lube oil sump
-
General
- Cast iron, engine block
- Cast iron exhaust manifold--side outlet
- Cold start capability to -20° C (-4° F)
- Gradeability 35° continuous
- Paint: Caterpillar yellow, with optional colors available at request
