Cat?� C15 Industrial Power Unit
-
Minimum Rating440.0 bhp
-
Maximum Power540 HP
-
Maximum Power540 hp
-
Maximum Rating540.0 bhp
Power Rating
- Minimum Rating
- 440.0 bhp
- Maximum Power
- 540 HP
- Maximum Power
- 540 hp
- Maximum Rating
- 540.0 bhp
- Rated Speed
- 1800-2100 rpm
- Rated Speed
- 1800-2100 rpm
- Minimum Power
- 440 HP
- Minimum Power
- 440 hp
- Rated Speed
- 1800-2100 rpm
- Minimum Rating
- 440 BHP
- Maximum Rating
- 540 BHP
Emission Standards
- Emissions
- China Stage II, U.S. EPA Tier 3 Equivalent, EU Stage IIIA Equivalent
- Emissions
- China Stage II, U.S. EPA Tier 3 Equivalent, EU Stage IIIA Equivalent
- Emissions
- China Stage II, U.S. EPA Tier 3 Equivalent, EU Stage IIIA Equivalent
General
- Engine Configuration
- Inline 6, 4-Stroke-Cycle Diesel
- Engine Configuration
- Inline 6, 4-Stroke-Cycle Diesel
- Engine Configuration
- Inline 6, 4-Stroke-Cycle Diesel
- Bore
- 5.4 in
- Bore
- 5.4 in
- Bore
- 137.2 mm (5.4 in)
- Bore
- 137.2 mm (5.4 in)
- Stroke
- 6.8 in
- Stroke
- 6.8 in
- Displacement
- 927.6 in³
- Displacement
- 927.6 in³
- Stroke
- 171.4 mm (6.75 in)
- Stroke
- 171.4 mm (6.75 in)
- Compression Ratio
- 18.0:1
- Compression Ratio
- 18.0:1
- Aspiration
- Turbocharged Aftercooled (TA)
- Aspiration
- Turbocharged Aftercooled (TA)
- Displacement
- 15.2 L (927.56 in³)
- Displacement
- 15.2 L (927.56 in³)
- Aspiration
- Turbocharged Aftercooled (TA)
- Rotation from Flywheel End
- Counterclockwise
- Rotation from Flywheel End
- Counterclockwise
- Compression Ratio
- 18:1
- Aftertreatment
- -
- Aftertreatment
- -
- Rotation
- Counterclockwise
Power Unit Dimensions
- Length
- 96.4 in
- Length
- 96.4 in
- Width
- 51.8 in
- Width
- 51.8 in
- Height
- 103.5 in
- Height
- 103.5 in
- Weight
- 4532 lb
- Weight
- 4532 lb
Power Unit Dimensions (Approximate. Final dimensions dependent on selected options)
- Length
- 2447.7 mm (96.4 in)
- Width
- 1316.6 mm (51.8 in)
- Height
- 2629.5 mm (103.5 in)
Power Unit Dimensions - Approximate
- Weight
- 2055 kg (4531.5 lb)
- Width
- 1316.6 mm (51.8 in)
- Height
- 2629.5 mm (103.5 in)
- Length
- 2447.7 mm (96.4 in)
-
Air Inlet System
- Turbocharged
- Air-to-Air Aftercooled
-
Control System
- Electronic governing, PTO speed control
- Programmable ratings
- Automatic altitude compensation
- Power compensation for fuel temperature
- Programmable low and high idle and total engine limit
- Electronic diagnostics and fault logging
- Engine monitoring system SAE J1939 broadcast and control
- ADEM™ A4 Electronic Control Unit (ECU)
-
Cooling System
- Thermostats and housing, vertical outlet
- Jacket water pump, centrifugal
- Water pump, inlet
-
Exhaust System
- Exhaust manifold, dry
- Optional exhaust outlet
-
Flywheels and Flywheel Housing
- SAE No. 1 flywheel housing
-
Fuel System
- MEUI injection
- Fuel filter, secondary (2 micron)
- ACERT™ Technology
- Fuel transfer pump
- Fuel priming pump
-
Lube System
- Crankcase breather
- Oil cooler
- Oil filler
- Lube oil filter
- Front sump oil pan
- Oil dipstick
- Gear driven oil pump
-
General
- Vibration damper
- Lifting eyes
- Cold start capability to -20° C (-4° F)
- Paint: Caterpillar yellow, with optional colors available at request
