New 3508C Land Mechanical Drilling Engine for Sale

3508C Land Mechanical Drilling Engine

Minimum Rating

900.0 bhp
Maximum Rating

900 BHP
Maximum Rating

900.0 bhp
Emissions

U.S. EPA Non-road Tier 2

Engine Specifications

Minimum Rating: 900.0 bhp
Maximum Rating: 900 BHP
Maximum Rating: 900.0 bhp
Emissions: U.S. EPA Non-road Tier 2
Emissions: U.S. EPA Non-road Tier 2
Displacement: 2111 in³
Rated Speed: 1200.0 RPM
Minimum Rating: 900 BHP
Bore: 6.69 in
Bore: 6.69 in
Stroke: 7.48 in
Stroke: 7.48 in
Displacement: 2111.0 in3
Rated Speed: 1200 r/min
Aspiration: Turbocharged-Aftercooled
Aspiration: Turbocharged-Aftercooled
Governor and Protection: ADEM A3
Engine Weight: 10101.0 lb
Engine Weight: 10101 lb
Oil Change Interval: 500
Rotation: Counterclockwise
Oil Change Interval: 500
Rotation from Flywheel End: Counterclockwise
Flywheel and Flywheel Housing: SAE No. 00
Flywheel and Flywheel Housing: SAE No. 00
Flywheel Teeth: 183
Flywheel Teeth: 183

Capacity for Liquids

Minimum Cooling System: 27.2 gal (US)

Dimensions

Length: 84.1 in
Length: 84.1 in
Width: 67.0 in
Width: 67 in
Height: 79.7 in
Height: 79.7 in

Air Inlet System
- Separate circuit aftercooler core — corrosion resistant coated (airside), air cleaner (single element w/service indicator)
- Dual rear-mounted turbochargers
Control System
- ADEM A3 ECU — LH
- Electronic fuel injector fuel system (10 amp DC power required todrive electronic engine control unit)
Cooling System
- Torque converter connections
- Thermostats and housing, jacket water pump, gear-drivencentrifugal
- Connections for radiator cooling
- Dual outlets: 88.9 mm O.D. (3.5 in) elbow hose connections
- Separate Circuit Aftercooler (SCAC)
Exhaust System
- Exhaust manifold — dry, stainless steel bellows
- Dual turbochargers with watercooled bearings
- Exhaust outlet: 292 mm I.D. (11.5 in), 12-10.5 mm dia. holes EQ SP,376 mm bolt hole dia.
Flywheels and Flywheel Housing
- Flywheel, SAE No. 0 — 151 teeth
- Flywheel housing — SAE No. 0
Fuel System
- Primary fuel filter
- Fuel priming pump
- Fuel filter — RH spin-on type
- Fuel transfer pump
- Electronically controlled unit injectors
Instrumentation
- Electronic instrument panel
- Instrumentation readouts:
Lube System
- Crankcase breather — top-mounted
- Oil cooler
- Oil filler and dipstick — RH
- Oil pump
- Oil filter — RH spin-on type
- Rear sump oil pan, 250-hour change interval
- Oil pan drain valve — 3/4" NPT female connection
Mounting System
- Rails — mounting, floor type
Power Take-Offs
- Front housing — two-sided
Protection System
- ADEM A3 ECU system to provide customer-programmableengine deration strategies to protect against adverse operatingconditions
- Emergency stop logic inputs provided at 40-pin customer interfaceconnection
- Air inlet shutoff
General
- Paint — Cat yellow
- Vibration damper and guard
- Lifting eyes
- B-Series LAND

Air Inlet System
- Air cleaner and air cleaner mounting
- Remote air inlet adapters
- Air inlet heater
Charging System
- Battery chargers
- Charging alternators
Control System
- Local speed throttle control
- Throttle position sensors
- Load sharing modules
- Governor conversion
Cooling System
- High gloss black folded core radiators
- Coolant regulator conversion
- Belt guard and radiator guard
- Blower fan
- Radiator cover
- Fan drive and fan pulleys
- Water level switch gauge
- Coolant level sensors
- Coolant conditioner
- Expansion tank
- Heat exchanger cooling conversion
- Auxiliary water pump
- Air separator
Exhaust System
- Flexible exhaust fitting
- Elbows and flange
- Flange and exhaust adapters
- Manifold and mufflers
Fuel Systems
- Flexible fuel lines
- Fuel cooler
- Water/fuel separator
- Fuel level switch
Instrumentation
- Customer management device
- Remote panel display and remote cylinder temperature display
- Switches and contactors
- Gauges and instrument panels
Lube System
- Fumes disposal
- Oil pans
- Prelube options
- Sump pumps
- Oil Filters
Mounting System
- Vibration isolators
Power Take-Offs
- Front housing
- Flexible couplings
- Coupling hub
- Front accessory drives
- Auxiliary drive shaft
- Auxiliary drive pulleys
- Front stub shaft
- Damper guard removal
- Pulleys
- Flywheel stub shaft
Protection System
- Shutoffs
- Switches and contractors
- Explosion relief valve
- Sensors
- Oil pressure monitor
- Shutoff controls
- Corrosion protection
Starting System
- Air starting motors — electric
- Air pressure regulator
- Air silencer
- Air start controls — manual, electric
- Redundant start
- Starting aids
- Battery sets – 24V
- Battery cable and battery rack
