Land Electric-Drive Modules

3516B Land Electric-Drive Drilling Module

  • Emissions
    Non-certified
  • Emissions
    Non-certified
  • Engine Control and Protection
    ADEM A3
  • Generator
    SR4B
Engine Specifications
Emissions
Non-certified
Emissions
Non-certified
Engine Control and Protection
ADEM A3
Generator
SR4B
Aspiration
Turbocharged-Aftercooled
Bore
6.69 in
Stroke
7.48 in
Displacement
4210.0 in3
Fuel System
EUI
Oil Change Interval
500.0 hr
Weight
41469.0 lb
Voltage
600
Aspiration
Turbocharged-Aftercooled
Bore
6.69 in
Displacement
4210 in³
Engine Control and Protection
ADEM A3
Fuel System
EUI
Generator
SR4B
Oil Change Interval
500 h
Stroke
7.48 in
Weight
41469 lb
Dimensions
Width
93.9 in
Length
310.0 in
Height
99.2 in
Height
99.2 in
Length
310 in
Width
93.9 in
Capacity for Liquids
Lube Oil System
107.0 gal
Cooling System
61.5 gal
Cooling System
61.5 gal (US)
Lube Oil System
107 gal (US)
  • Air Inlet System
    • Corrosion-resistant aftercooler core
    • Air Inlet shutoff
    • Regular duty air cleaner
  • Control System
    • ADEM A3 ECU, left-hand mounted
    • Direct rack control 0-200 mADC, space heater and jacket water heater connection and controls
  • Cooling System
    • Separate-circuit aftercooled
    • Outlet controlled jacket water thermostat
    • Jacket water pump - gear driven
    • Dual outlet
    • Aftercooler water pump - gear driven
    • Aftercooler water thermostat
  • Exhaust System
    • Dry exhaust manifold
    • Dual turbochargers, water cooled bearings
  • Flywheel and Housing
    • SAE No. 00 flywheel
    • SAE No. 00 flywheel housing
    • SAE standard rotation
  • Fuel System
    • Fuel filter simplex (LH) with priming pump (LH)
    • Fuel transfer pump
    • Fuel return line with flexible connection
    • Electronic unit injectors
  • Generator Attachments
    • Barrel-mounted petroleum terminal box with air filter and pressure differential switch
  • Instrumentation
    • Emergency stop button
    • Analog gauges:
    • Service port connector
    • Customer connection terminal blocks
  • EMCP 4.3 Control Panel
    • 140 mm (5.5 in) Graphical Display
    • Communication
    • Controls
    • Generator Set Protection
    • Outputs
    • Inputs
    • Other Features
  • Lubrication System
    • Crankcase breather
    • Oil cooler
    • Shallow oil pan
    • Oil drain extension, 2 in NPT female connection
    • Simplex oil filter
  • Mounting System
    • 4.19 m (165 in) length, 412 mm (16.2 in) height tubes, 1.18 m (50.5 in) wide
  • Protection System
    • Engine alarms, derate, and shutdown in abnormal operation
  • Starting System
    • TDI air starting motor, RH - 1034 kPa (150 psi)
  • General
    • Paint - Cat yellow
  • Air Inlet System
    • Heavy duty air cleaner
    • Remote air inlet adapter - rectangular
    • Remote air inlet adapter - round
  • Control System
    • Engine control options:
    • Load sharing governor, 2301A
  • Cooling System
    • Radiator options:
    • Coolant level sensor
    • Coolant conditioner
    • Cooling system connection options (for use with customer-supplied radiator):
    • Fan drive and belt guard (for use with remote and customersupplied radiators)
    • Fan pulley options (for use with customer-supplied radiator):
  • Exhaust System
    • 1200 rpm model only:
    • 1500 rpm model only:
  • Fuel System
    • Custom fuel filter
    • Primary fuel filter
    • Primary fuel filter with water separator
  • Generator Attachments
    • Cable access box
    • Air filter
    • Bearing RTDs
    • Low voltage extension box
    • Manual voltage control
  • Instrumentation
    • Communications module PL1000T
    • Communications module PL1000E
    • Thermocouples installed, one per cylinder
  • Lubrication System
    • Custom oil filter
    • RH installed centrifugal oil filter
    • SAE15W40, Caterpillar DEO, 500 hour
    • Crankcase fumes disposal
    • Oil level regulator
  • Mounting System
    • Bases
    • Vibration isolators, rails
  • Power Take-off
    • Alternator, 24V, 68A
    • Front accessory drive
    • Pulleys
  • Protection System
    • Explosion relief valves (3)
    • Metal particle detector switch
    • Metal particle detector with annunciator
  • Starting System
    • Custom starting motor
    • Air pressure regulator
  • General
    • LH installed engine barring group
    • Jacket water heater, UL recognized, 120-240V, single phase, 6 kW, LH and RH mounted
    • Jacket water heater, UL recognized, 120-480V, single phase, 12 kW, LH and RH mounted
    • Jacket water heater lines
