Marine Generator Sets
Cat C280-12 Marine Generator Set
-
Minimum Rating3520 ekW (4400 kVA)
-
Power Range3640 - 3520 ekW
-
Maximum Rating3640 ekW (4550 kVA)
-
Frequency50 Hz or 60 Hz
Generator Set Specifications
- Minimum Rating
- 3520 ekW (4400 kVA)
- Maximum Rating
- 3640 ekW (4550 kVA)
- Frequency
- 50 Hz or 60 Hz
- Frequency
- 50 Hz or 60 Hz
- Speed
- 1000 rpm (50 hz) or 900 rpm (60 hz)
- Speed
- 1000 rpm (50 hz) or 900 rpm (60 hz)
- Minimum Rating
- 3520 ekW (4400 kVA)
- Maximum Rating
- 3640 ekW (4550 kVA)
- Emissions
- EPA Tier 2, IMO II
Power Rating
- Power Range
- 3640 - 3520 ekW
Engine Specifications
- Emissions
- EPA Tier 2, IMO II
- Engine Model
- Vee 12, 4-Stroke-Cycle Diesel
- Aspiration
- Turbocharged-Aftercooled
- Aspiration
- Turbocharged-Aftercooled
- Bore
- 11.0 in
- Bore
- 11 in
- Stroke
- 11.8 in
- Stroke
- 11.8 in
- Displacement
- 13546.0 in3
- Displacement
- 13546 in³
- Governor Type
- Electronic
- Governor Type
- Electronic
- Fuel System
- EUI
- Compression Ratio 50 Hz
- 13.1
- Compression Ratio 60 Hz
- 13:1
- Engine Model
- V 12, 4-Stroke-Cycle Diesel
Generator Set Configurations
- Emissions
- EPA Tier 2, IMO II
Generator Set Dimensions
- Length
- 316.5 in
- Length
- 316.5 in
- Width
- 77.2 in
- Width
- 77.2 in
- Height
- 155.0 in
- Height
- 155 in
- Weight
- 25000.0 lb
- Weight
- 25000 lb
-
General
- LH and RH service availability
-
Air Inlet System
- Aftercooler — fresh water, corrosion resistant coated (air side)
- Crankcase breathers, top mounted
- Air inlet adapter - Straight / 90 degree / 35 degree
-
Air Inlet Sytem
- Dual turbochargers, rear-mounted, engine oil lubricated
-
Control System
- Dual Caterpillar ADEM A4 Electronic Engine Control Modules
- Rigid Wiring Harness
-
Cooling System
- Aftercooler / oil cooler and jacket water pumps (gear driven)
- Engine coolant water drains
- Single Circuit / Separate Circuit Aftercooler
-
Exhaust System
- Dry, gas tight, exhaust manifold
- Turbo speed sensors - overspeed protection
-
Fuel System
- Fuel transfer pump, gear driven
- Duplex Fuel filters
- Electronically Controlled Unit Injectors
-
Insrumentation
- CAT Alarm & Protection System
-
Lube System
- Oil pump, gear driven
- 3 element oil cooler, engine mounted
- Duplex centrifugal oil filter - engine mounted
- Prelube pump - air / electric
-
Protection System
- Cylinder pressure relief valves
-
Exhaust System
- Exhaust manifold shielding - soft
-
Fuel System
- SOLAS shielding
-
Lube System
- Front and rear oil pan drains
- Wet sump
- SOLAS shielding
-
Protection Sytem
- Oil mist detector
-
Protection System
- Cylinder pressure relief valves
