Cat C280-16 Marine Generator Set
-
Minimum Rating4700 ekW (5875 kVA)
-
Power Range4700 - 4840 ekW
-
Maximum Rating4840 ekW (6050 kVA)
-
Frequency50 / 60
Generator Set Specifications
- Minimum Rating
- 4700 ekW (5875 kVA)
- Maximum Rating
- 4840 ekW (6050 kVA)
- Frequency
- 50 / 60
- Frequency
- 50 Hz or 60 Hz
- Speed
- 1000 rpm (50 hz) or 900 rpm (60 hz)
- Speed
- 1000 rpm (50 hz) or 900 rpm (60 hz)
- Minimum Rating
- 4700 ekW (5875 kVA)
- Maximum Rating
- 4840 ekW (6050 kVA)
- Emissions
- EPA Tier 2, IMO II
Power Rating
- Power Range
- 4700 - 4840 ekW
Engine Specifications
- Emissions
- EPA Tier 2, IMO II
- Aspiration
- Turbocharged-Aftercooled
- Aspiration
- Turbocharged-Aftercooled
- Bore
- 11.0 in
- Bore
- 11 in
- Stroke
- 11.8 in
- Stroke
- 11.8 in
- Displacement
- 18062.0 in3
- Displacement
- 18062 in³
- Governor Type
- Electronic
- Governor Type
- Electronic
- Fuel System
- EUI
- Compression Ratio 50 Hz
- 13.1
- Compression Ratio 60 Hz
- 13:1
- Engine Model
- Vee 16, 4-Stroke-Cycle Diesel
- Engine Model
- Vee 16, 4-Stroke-Cycle Diesel
Generator Set Configurations
- Emissions
- EPA Tier 2, IMO II
Generator Set Dimensions
- Length
- 366.7 in
- Length
- 366.7 in
- Width
- 78.3 in
- Width
- 78.3 in
- Height
- 164.1 in
- Height
- 164.1 in
- Weight
- 31000 kg/ 68343 lb (engine dry weight), 18145 kg/ 40000 lb (generator weight)
- Weight
- 31000 kg/ 68343 lb (engine dry weight), 18145 kg/ 40000 lb (generator weight)
-
Air Inlet System
- Aftercooler — fresh water, corrosion resistant coated (air side); air inlet shutoff; breather — crankcase, top-mounted; turbocharger — engine oil lubricated
-
Control System
- Single Caterpillar® A3 electronic control unit (ECU) with electronic unit injector fuel system, rigid wiring harness (10 amp, 24 volt power required to drive ECUs)
-
Cooling System
- Engine coolant water drains
-
Exhaust System
- Dry, gas tight, exhaust manifold
-
Fuel System
- Distillate fuel (requires viscosity ranging from 1.4 cSt to 20 cSt at 38° C), fuel transfer pump (mounted on left-hand side), duplex fuel filters, electronically controlled unit injectors
-
Lube Oil System
- Centrifugal oil filters with single shutoff, service side engine mounted on cylinder block inspection covers includes installed oil lines and single shutoff valve, filters centrifuge bypass oil from the main lubricating oil pump, can be serviced with the engine running, oil filler and dipstick valve, oil pressure regulating valves, crankcase explosion relief valves
-
General
- Caterpillar yellow paint; gear-driven pumps: fuel, oil, jacket water, aftercooler/oil cooler water; service literature
