Offshore Drilling and Production Generator Sets

8CM34DF

  • Minimum Rating
    4800 kV·A
  • Maximum Rating
    4800 kV·A
  • Emissions
    IMO Tier II
  • Aspiration
    Turbocharged Aftercooler
Engine Specifications
Minimum Rating
4800 kV·A
Maximum Rating
4800 kV·A
Emissions
IMO Tier II
Aspiration
Turbocharged Aftercooler
Engine Control
Electronic
Weight
187000 lbs
Stroke
18.1 in
Bore
13.4 in
Displacement
20382 in3
Aspiration
Turbocharged Aftercooler
Bore
13.4 in
Displacement
20382 in³
Engine Control
Electronic
Stroke
18.1 in
Weight
187000 lb
Dimensions
Length
425 in3
Width
102.4 in
Height
213.1 in
Height
213.1 in
Length
425 in³
Width
102.4 in
  • Engine
    • Motor-driven barring gear, fitted on engine
    • Emergency shutdown equipment with pushbutton for manual emergency stop
  • Cylinder Heads
    • Fuel injector and integrated gas admission valve with easy service and maintenance access
    • Cylinder pressure sensors for highest operational reliability and efficiency, replacing conventional knocking sensor technology
    • Piston, rings and liners designed for operation on gas and liquid fuels
  • Turbocharger
    • Optimized engine efficiency in gas and diesel operation
    • Blow-off valve and waste gate technology for optimized air-fuel ratio control
  • Gas System
    • Double-walled gas piping to support an inherently safe engine room concept
    • Leakage detection
    • Gas valve unit
    • Segmented gas detection system on request
  • Micro Pilot Fuel Injection System
    • Gear driven high pressure fuel pump and filter system with easy service access
    • Reliability combined with service and maintenance simplicity, through individual ignition fuel injector and “in-cylinder head” integrated ignition fuel return pipes.
  • Exhaust System
    • Front-mounted turbocharger at free end with transition nozzle (0 degrees from the vertical and away from engine),
    • Expansion joint separate
    • Separate silencer and spark arrester
  • Fresh Cooling Water System
    • HT pump, fitted on engine
    • LT pump, separate, vertical design, electric motor driven
    • HT thermostat, remote-mounted, electric controlled
    • Cooling water preheating equipment, fitted on base frame
  • Lubricating Oil System
    • Plate cooler, fitted on engine
    • Force pump, fitted on engine
    • Pre-lubrication pump, fitted on base frame, electric motor driven
    • Automatic back-flushing filter
    • Duplex filter with differential pressure indication, fitted on engine
    • Pressure control valve, fitted on engine
    • Thermostat, remote-mounted, electric controlled
  • Connections
    • Set of connecting parts between flange coupling and flywheel
    • Flexible flange coupling between engine and generator
    • Base frame with flywheel guard and incorporating lube oil sump tank, for engine and generator
    • Mounting of engine and generator on the base frame
    • Set of bonded rubber rails for resilient mounting of the base frame
    • Set of flexible pipe connections
  • Instrumentation
    • Gauge board with liquid-dampened pressure gauges for: fuel, lubricating oil, fresh water, starting air and charge air.
    • On-engine thermometers for fuel, lubricating oil, fresh water and charge air
    • Electric remote speed indicator
    • Turbocharger and remote speed indicator
    • Exhaust gas temperature indicator
  • Monitoring
    • Manual control on engine, including: control panel with start/stop key, speed setting device, mechanical shutdown device, changeover of control functions from engine to remote control
    • Starting solenoid valve on engine, 24 V DC
    • Separate electronic speed governor
