New C9 ACERT™ Dry Manifold Engine for Sale

C9 ACERT™ Dry Manifold Engine

Maximum Rating

375 BHP
Displacement

538 in³
Minimum Rating

205 BHP
Governor and Protection

Electronic (ADEM™ A3)

General Specifications

Maximum Rating: 375 BHP
Displacement: 538 in³
Minimum Rating: 205 BHP
Governor and Protection: Electronic (ADEM™ A3)
Aspiration: Turbocharged-Aftercooled
Flywheel and Flywheel Housing: SAE 1 or 2
Flywheel Teeth: 113 (SAE 1), 134 (SAE 2)
Rotation from Flywheel End: Counterclockwise
Stroke: 5.8 in
Bore: 4.41 in

Emissions

Emissions: EPA and CARB Non-Road Tier 3, EU Stage IIIA, IMO Tier II

Dimensions

Length: 43.0 in.
Length: 43 in
Width: 32.6 in.
Width: 32.6 in
Height: 40.3 in.
Height: 40.3 in
Weight: 1578.0 lb
Weight: 1578 lb

Capacity for Liquids

Lube Oil System: 8.0 gal
Lube Oil System: 8 gal (US)
Cooling System: 3.7 gal (US)

Air Inlet System
- Turbocharger, separate circuit (SCAC) or remote (REMAC) aftercooler
- Single, right-side, center-mounted turbo with water-cooled turbine housing
- Air inlet 101.6 mm (4 in) connection type
Control System
- Electronic governing, PTO speed control
- Programmable ratings
- Cold mode start strategy
- Automatic altitude compensation
- Fuel cooled ECU
- Power compensation for fuel temperature
- Programmable low and high idle
- Electronic diagnostics and fault logging
- Programmable monitoring system (engine speed, temperature, pressure)
- J1939 broadcast (diagnostic and engine status)
- Electronic installation kit (connectors, PINS, sockets) (nonhazardous environment only)
- Certified electrical control system (hazardous environment only)
- Derated engine: automatic ambient temperature compensation
Cooling System
- Thermostats and housing, RH forward-facing outlet — 51 mm (2.01 in) connection
- Jacket water pump — belt-driven, centrifugal
- Water pump — inlet RH facing downward 63 mm (2.48 in)
Exhaust System
- Exhaust manifold — water-cooled
- Single, center right-side mounted turbo with water-cooled turbine housing
- Rear facing turbo exhaust 81.8 mm (3.22 in.) connection, non V-band clamp
Flywheels and Flywheel Housings
- Mandatory selection of: SAE No. 1 or SAE No. 2 flywheel and housing, SAE standard rotation
Fuel System
- HEUI fuel system
- Fuel filter — secondary, LH (2-micron high performance)
- Fuel transfer pump — left front
- Fuel priming pump — left front
Lube System
- Crankcase breather — LH
- Crankcase fumes disposal with integrated service indicator, LH
- Oil cooler — RH
- Oil filter — RH
- Oil pan — front sump
- Oil filler — top mounted
- Oil level gauge — LH side
- Oil pump — gear-driven
- Oil valve sampling
- Preservation of turbocharger, flywheel, and crankcase
Power Take-Offs
- Crankshaft drive pulley — 2 grooves, 190 mm (7.5 in) diameter, 22.3 mm (7/8 in) wide
General
- Vibration damper
- Lifting eyes
- Automatic variable timing — electronic
- Literature
Mandatory Options
- Flywheel housing and flywheel
- Throttle position sensor and/or throttle control (non-hazardous environment only)
- Primary filter/water separator
- Turbo orientation

Air Compressor
- Air compressor governor
Air Inlet System
- Air cleaners
- Precleaner
- Air inlet elbow
- Air shutoffs
Charging Systems
- Charging alternators
- Alternator mountings and pulleys
- Alternator belt tensioner
Cooling System
- Radiators
- Radiators
- Fans f/u/w radiator packages
- Coolant level sensor
- Fan drive mountings, adapters, pulleys
- Vee belts for customer-supplied radiators
- Suction fans and blower fans
- Water inlet elbows
- Dry charge coolant conditioners
Emissions Certification
- IMO Certification
Exhaust System
- Flexible fitting
- Turbocharger exhaust outlet adapters
- Elbows, flange, pipes, clamp
- Rain caps
- Manifolds
- Mufflers
Flywheels and Flywheel Housings
- Crankshaft seal
Fuel System
- Flexible fuel lines
- Water separator and fuel filters
- Fuel cooler
Instrumentation
- Gauges and instrument panels
- Interconnect harnesses
- Voltmeters
- Gauge mounting
- Ammeter
Lube System
- Oil pan
- Drain and cover
- Oil level gauges
- Remote oil filter
- Oil fillers
- Lubricating oil
- Fumes disposal
- Fumes disposal mounting
Mounting System
- Structural steel base
- Front and rear engine supports
Power Take-Offs
- Enclosed clutch
- Clutch supports
- Flywheel stub shaft
- Hydraulic pump drives
- Hydraulic gear pumps
- Pulley
Starting System
- Starting aids
- Electric starting motors — 12V and 24V
- Battery sets — 12V and 24V (dry)
- Battery cable
Transmission Arrangement
- Transmission cooler
General
- Tool set
